Homeline 100 Amp 10-Space 20-Circuit Outdoor Ring-Type Overhead Main Breaker CSED Value Pack
Homeline 100 Amp 10-Space 20-Circuit Outdoor Ring-Type Overhead Main Breaker CSED Value Pack
Regular price
$148.85 USD
Regular price
$0.00 USD
Sale price
$148.85 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Low stock: 10 left
- Compatible with Square D Homeline breakers except Plug on Neutral
- 4-jaw meter socket and aluminum bus bar included
- Contact your local utility company to ensure requirements are met
The Square D 100 Amp 10-Space 20-Circuit Outdoor Combination meter Socket and Main Breaker Load Center, Model SO1020M100S, is suitable for use as a combination service entrance device (CSED). This unit is ANSI certified and UL listed with a maximum 10,000 AIR. The combination service entrance device features a Ring-type meter cover with a single-phase, 4-jaw meter socket. It is suitable for only overhead service applications. Meets EUSERC Specifications. Surface mount. This CSED is built with a plated, aluminum bus bar that is tested and is compatible with Square D Homeline circuit breakers, except Plug-On Neutral breakers. Homeline CSEDs are designed for the value-minded contractors, remodelers, builders and homeowners. Square D Homeline CSEDs are engineered for fast installation and wire savings.
13.46 inches x 4.56 inches x 20.79 inches. Weight: 23.75 lb
| Bypass Type | No Bypass |
| Electrical Product Type | Load Center |
| Included | No Additional Items Included |
| Indoor/Outdoor | Outdoor |
| Load Center Type | Combination |
| Maximum Amperage (A) | 100 A |
| Meter Socket Type | Ring |
| Mounting Type | Surface |
| NEMA Configuration | NEMA 3R |
| Number of Circuits | 20 |
| Number of Gangs | 1 |
| Number of Jaws | 4 |
| Number of Spaces | 10 |
| Phase Type | 1 Phase |
| Product Weight (lb) | 23.75 lb |
| Returnable | 90-Day |
| Service feed type | Overhead/underground |
| Solar Compatiblity | Not Solar Ready |
| Voltage (V) | 120/240 V |
| Certifications and Listings | ANSI Certified,UL Listed |
| Manufacturer Warranty | /Schneider Electric warrants its single-phase load centers and combination service entrance devices to be free from defects in material and workmanship, under normal care and proper usage in a residential installation, for a period of 10 years from the date of installation, when used with /Schneider Electric circuit breakers. |
| Load center depth (in) | 4.56 |
| Load center height (in) | 20.79 |
| Load center width (in) | 13.46 |
| Product Depth (in) | 4.56 in |
| Product Width (in) | 13.46 in |
